CNC corrugated box cutting machine with knife cutting and creasing tools. No die needed. High precision for carton & packaging boxes.

Name: CNC corrugated box cutting machine with knife cutting and creasing tools. No die needed. High precision for carton & packaging boxes.
Brand: IBON Technology Co., Ltd.
SKU: IB1625
Price: 144,999.00 USD
Availability: InStock

ブランド名:	IBON
モデル番号:	IB1625
MOQ:	1
支払条件:	T/T
供給能力:	300set/month

詳細情報

製品の説明

詳細情報

Place of Origin:

DongGuan, China

証明:

製品名:

CNC カードボード切断機

給餌方法:

自動飼料材料

空気圧:

0.75-0.85Mpa

切断精度:

±0.1mm

切断厚さ:

0.1~30mm (材料によって)

伝達モーター:

日本三?? 市

送信モード:

線形レールとラック

データ形式:

Plt,Dxf について

トランスミッションインターフェース:

イーサネット,USB

固定モード:

真空は吸収する

定格電圧:

AC220V~380V,50HZ

定格電力:

約10KW

Packaging Details:

Wooden Case

ハイライト:

Automatic feeding material CNC Cardboard Cutting Machine

±0.1mm Cutting accuracy Corrugated Box Cutting Machine

1600 × 2500 mm Working Area Carton Box CNC Cutter

製品の説明

IB1625 Corrugated Box Cutting Machine | Carton Box CNC Cutter

The IB1625 corrugated box cutting machine is a professional carton box CNC cutter designed for digital cutting and creasing of cardboard, carton paper, and corrugated packaging boxes. It is widely used in packaging factories, printing houses, and custom box manufacturers.

Equipped with a dual tool holder system, the IB1625 integrates CNC knife cutting and creasing (folding) functions in one machine, allowing cutting and creasing to be completed in a single operation without changing tools.

CNC Knife Cutting & Creasing in One System

CNC knife cutting tool for precise cutting of corrugated board, carton paper, and cardboard
Creasing tool for accurate folding lines, ensuring perfect box forming
Two tool holders with two machine tools, specially configured for packaging box production

This configuration makes the carton box CNC cutter highly efficient for producing corrugated boxes, packaging cartons, display boxes, and customized packaging.

Technical Specifications

Model NO.	1625
Certification	CE, ISO 9001:2000
Condition	New
Control	Automatic
Application	Paper, Plastic, Leather, Fabric
Power Source	Electric
Layout	Vertical
Working Area	1600*2500mm
Method of Fixing Material	Vacuum Suction
Transmission	Rack
Driving	Servo
Transport Package	Wood Crate
Specification	1625
Trademark	IBON
Origin	DongGuan, China
HS Code	84411000
Production Capacity	300 Set/Month

Customizable Working Size

The standard working size of the IB1625 carton box CNC cutter is 1600 * 2500 mm, and customized machine sizes are available to meet different production requirements.

Whether you are producing corrugated packaging boxes, carton boxes, or cardboard displays, the IB1625 CNC corrugated box cutting machine provides a flexible, efficient, and cost-effective digital cutting solution.

The IB1625 is an ideal corrugated box cutting machine and carton box CNC cutter for manufacturers seeking high precision, fast setup, and zero die cost.

Tool System Introduction

Oscillating knife: to cut off or half cut the cardboard, corrugated cardboard, honeycomb cardboard, gray board, etc.

Creasing wheel: Creasing wheel tool used to press the marks for folding the carton, also can process easy tear off carton dotted line cutting.

V cut tool: for slotting and bevel cutting on honeycomb cardboard or corrugated cardboard.

CCD Camera: for read patterns on the printed cardboard, and then machine cut along the edge.

Pneumatic knife tool: for cutting thick or hard cardboard, foam board, etc. More powerful.
